FRAME
Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
FORK
FOX 34 Float Performance Air Grip 3, 3-Modes / Kabolt 15x110mm axle / tapered steerer, 44mm offset / Reb. Adj. / Lockout / 130mm travel
REAR SHOCK
FOX NUDE 5T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Custom large Air volume / DPS / Reb. Adj., Travel 120-80-Lockout / T165X45mm
REMOTE SYSTEM
SCOTT TwinLoc 2 TechnologySuspension & Dropper Remote, 3 Suspension modes
REAR DERAILLEUR
SRAM GX Eagle 12 Speed
SHIFTERS
SRAM GX Eagle Trigger
CRANKSET
SRAM GX Eagle DUB, 55mm CL / 32T
BB-SET
SRAM DUB PF 92 MTB Wide / shell 41x92mm
CHAIN
SRAM CN NX Eagle
CASSETTE
SRAM XG1275 / 10-52 T
BRAKES
Shimano SLX M7120 4 Piston Disc
ROTOR
Shimano SM-RT66 / 6 Bolt / F&R 180mm
HANDLEBAR
Syncros Fraser 1.5 DC Alloy 7075 D.B., mini Rise / back sweep 8° / 760mm, Syncros Pro lock-on grips
H'STEM
Syncros DC 1.5, Syncros Cable Integration System, 0° rise / 7050 Alloy / 31.8mm / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.0, 31.6mm / S & M size 125mm / L & XL size 150mm
SEAT
Syncros Tofino 2.0 Regular, CRMO rails
HEADSET
Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
WHEELSET
Syncros Silverton 2.5-30 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
FRONT TIRE
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Soft
REAR TIRE
Schwalbe Wicked Will 29x2.4" EVO, Super Race / TLE / 67EPI / Addix Speed Grip
APPROX WEIGHTS IN KG
12.8 (Tubless setup)
APPROX WEIGHTS IN LBS
28.22 (Tubless setup)
MAX. SYSTEM WEIGHT
128 kg
