FRAME
Ransom Alloy SL 6011, Custom butted / VLK Virtual 4 Link kinematic, 27.5" (2.6 & 2.8) and 29" (2.4 & 2.6) tire compatible with Geo-BB adj., TBC Trunnion box construction / Boost 12x148mm
FORK
FOX 38 Float Performance Air / GRIP / Comp Adj. / Reb. Adj. / 15x110mm QR axle, 44mm offset / 170mm travel
REAR SHOCK
FOX NUDE T EVOL Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, custom large air volume / DPS / Reb. Adj., Travel 170-120-Lockout / 205X65mm
REMOTE SYSTEM
TracLoc Technology, Rear Suspension & Dropper Remote, 3 Rear Suspension modes
REAR DERAILLEUR
SRAM NX Eagle 12 Speed
SHIFTERS
SRAM NX Eagle Trigger
CRANKSET
SRAM NX Eagle DUB Boost, 32T
CHAINGUIDE
SCOTT Chainguide
BB-SET
SRAM DUB PF integrated / shell 41x92mm
CHAIN
SRAM CN NX Eagle
CASSETTE
SRAM NX / PG1210 / 11-50 T
BRAKES
SRAM DB8 4 Piston Disc
ROTOR
SRAM Centerline Rotors / 6 Bolt / 200/F & 180/R
HANDLEBAR
Syncros Hixon 1.5 Rise / Alloy 20140D.B., 20mm rise / 8° / 780mm, Syncros Pro lock-on grips
H'STEM
Syncros XM1.5 / Alloy 6061, integrated Spacer & Top Cap / 31.8mm / 0° / 1 1/8"
SEATPOST
Syncros Duncan 2.0 Dropper Post, 31.6mm / S 125mm / M 150mm / L & XL 170mm
SEAT
Syncros Kaslo 2.0, Crmo Rails
HEADSET
Syncros Pro Press Fit E2 / Tapered 1.5"-1 1/8", OD 50/62mm / ID 44/56mm
WHEELSET
Syncros Revelstoke 2.5 6 Bolt, F: 15x110mm, R: 12x148mm Boost, 30mm Tubeless ready rim 28Hr, Syncros Axle w/Removable Lever with Tool
FRONT TIRE
Maxxis Assegai / 2.5" / 60TPI Foldable / EXO+ / TR / 3C Maxx Gripp
REAR TIRE
Maxxis Dissector / 2.4" / 120TPI Foldable / EXO+/ TR / 3C Maxx Terra
EXTRAS
Syncros Trail Fender 2 36/38
APPROX WEIGHTS IN KG
15.8 (with tubes)
APPROX WEIGHTS IN LBS
34.83 (with tubes)
MAX. SYSTEM WEIGHT
128kg
