FRAME
Alloy Frame & Link, Virtual 4 link kinematic VLK, 29x2.6 / Boost 148x12mm UDH, 160mm travel / Bosch Gen4 / Integr. removable Battery, 1.8" Headtube, Central Kickstand Mount, Integr. Cable
TRAVEL
Front: 160mm / Rear: 160mm
FORK
RockShox Domain Air, 15x110mm QR axle / 1.8" Tapered Steerer, Reb. Adj. / 2 Modes / Lockout / 160mm travel / E-Bike
REAR SHOC
KX-Fusion NUDE eRIDE Trunnion, SCOTT custom w. travel / geo adj., 3 modes: Lockout-Traction Control-Descend, Reb. Adj., Travel 160-115-Lockout / 205x60mm
REMOTE SYSTEM
SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 modes
DRIVE UNIT
Bosch Performance CX, EU: 25kmh / INT: 20mph
BATTERY
PowerTube 625Wh
DISPLAY
Bosch LED Remote
CHARGER
4A Charger
REAR DERAILLEUR
SRAM NX Eagle / 12 Speed
SHIFTERS
SRAM SX Eagle Single Click
CRANKSET
FSA CK-745 165mm / 34T
CHAINRING
SRAM Eagle 34T DM / Steel
CHAIN
SRAM SX Eagle
CASSETTE
SRAM PG1210 / 11-50 T
BRAKES
SRAM DB8 4 Piston Disc
ROTOR
Centerline CL Rotors 200mm F&R
HANDLEBAR
Syncros Hixon 2.0 / Alloy 6061D.B., 12mm rise / 9° / 780mm, Syncros Endurance lock-on grips
H'STEM
Syncros AM2.0 / 6061 Alloy, 31.8mm / 4° / 1 1/8"
SEATPOST
Syncros Duncan Dropper Post 2.5, 31.6mm / S size 125mm / M size 150mm / L size 170mm / XL size 200mm
SEAT
Syncros Tofino 2.5 Regular
HEADSET
Acros / 1.8", ZS66 OD74 / integr. Cable
HUB (FRONT)
Formula CL-811 / 15x110mm
HUB (REAR)
Formula ECT-1481 / Boost 148x12mm
SPOKES
Stainless Black
RIMS
Syncros MD30 / 32H / 30mm / Pin Joint, Tubeless ready
FRONT TIRE
Maxxis Dissector 29x2.6", 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra
REAR TIRE
Maxxis Dissector 29x2.6", 120TPI Foldable Bead, EXO+ / TR Tubeless ready, 3C Maxx Terra
LIGHTS
Syncros integrated rear fender light, Front Light Cable pre-installed
APPROX WEIGHTS IN KG
26.1 (with tubes)
APPROX WEIGHTS IN LBS
57.54 (with tubes)
MAX. SYSTEM WEIGHT
128kg
