Frame - Carbon HMF
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Range Extender Ready
Travel - Front: 160mm / Rear: 155mm
Fork - FOX 36 Float Rhythm Air Grip
3 modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 160mm travel
Rear Shock - FOX NUDE 6T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Low Speed Adj. / Custom large Air volume / Reb. Adj.
Travel 155-100-Lockout / T185X55mm
Remote System - SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Drive Unit - TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Battery - TQ Internal 360Wh
Display - TQ HPR Bluetooth / ANT+ / Dedicated Smartphone app
Charger - TQ 100-240V-4A
Rear Derailleur - Shimano XT RD-M8100 SGS Shadow Plus / 12 Speed
Shifters - Shimano Deore SL-M6100-IR / Rapidfire PlusI-spec EV clamp
Crankset - FSA Alloy crankset / 175mm / 34T
Chainguide - e*thirteen / e*spec Slider
Chainring - Scott custom spider / FSA 12Speed 34T chainring
Chain - Shimano CN-M6100
Cassette - Shimano CS-M6100 / 10-51 T
Brakes - Shimano Deore M6120 4-Piston Disc
Rotor - Shimano SM-RT64 CL / F&R 203mm
Handlebar - Syncros Hixon 1.5 Alloy 7050
Size S & M 15mm rise / Size L & XL 25mm rise
back sweep 8° / 780mm
Syncros Endurance lock-on grips
H'stem - Syncros AM 1.5
Syncros Cable Integration System
4° rise / 7050 Alloy / 31.8mm / 1 1/8"
Seatpost - Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mmS size 140mm / M size 180mm / L & XL size 210mm
Seat - Syncros Tofino 1.5 RegularTitanium rails
Headset - Syncros - Acros Angle adjust & Cable Routing HS System
Stainless / +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Hub (Front) - Formula CL-811 / 15x110mm
Hub (Rear) - Formula CL-148M / 12x148mm
Spokes - Stainless Black 15G / 1.8mm
Rims - Syncros X-30S / 32H / 30mm / Sleeve JointTubeless ready
Front Tire - Maxxis Dissector / 2.6" / 60TPI FoldableTubeless Ready / EXO 3C maxx Terra
Rear Tire - Maxxis Dissector / 2.6" / 60TPI FoldableTubeless Ready / EXO 3C maxx Terra
Extras - Syncros Fork Fender
Approx weight in KG - 19.5 (with tubes)
Approx weight in LBS - 42.99 (with tubes)
Max. System Weight - 128 kg The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
