Frame
Carbon HMFIntegrated Suspension TechnologyVirtual 4 Link kinematic / Adjustable head angleSyncros Cable Integration SystemTQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Travel
Front: 150mm / Rear: 155mm
Fork
Marzocchi Z2 Air Rail3 modes / 15x110mm QR axle / tapered steerer44mm offset / Reb. Adj. / Lockout / 150mm travel
Rear Shock
FOX Float Custom EVOL Performace Trunnion3 modes / Lockout-Trail-DescendDPS / Reb. Adj.Travel 155mm / T185X55mm
Remote System
SCOTT TwinLoc 2 TechnologySuspension & Dropper Remote3 Suspension modes
Drive Unit
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Battery
TQ Internal 360Wh
Display
TQ HPRBluetooth / ANT+ / Dedicated Smartphone app
Charger
TQ 100-240V-4A
Rear Derailleur
Shimano XT RD-M8100 SGSShadow Plus / 12 Speed
Shifters
Shimano Deore SL-M6100-IR / Rapidfire PlusI-spec EV clamp
Crankset
FSA Alloy crankset / 175mm / 34T
Chainguide
e*thirteen / e*spec Slider
Chainring
Scott custom spider / FSA 12Speed 34T chainring
Chain
Shimano CN-M6100
Cassette
Shimano CS-M6100 / 10-51T
Brakes
SRAM DB8 4 Piston Disc
Rotor
SRAM Centerline CL Rotors F&R 200mm
Handlebar
Syncros Hixon 2.0 Alloy 6061 D.B.12mm Rise / back sweep 8° / 780mmSyncros Endurance lock-on grips
H'stem
Syncros AM 2.0Syncros Cable Integration System4° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost
Syncros Duncan Dropper Post 2.531.6mm / S size 125mm / M size 150mm / L size 170mm
Seat
Syncros Savona 2.0
Headset
Syncros - Acros Angle adjust & Cable Routing HS SystemStainless / +-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front)
Formula CL-811 / 15x110mm
Hub (Rear)
Formula CL-148M / 12x148mm
Spokes
Stainless Black 15G / 1.8mm
Rims
Syncros X-30S / 32H / 30mm / Sleeve JointTubeless ready
Front Tire
Maxxis Dissector / 29x2.6" / 60TPI Wire BeadEXODual
Rear Tire
Maxxis Dissector / 29x2.6" / 60TPI Wire BeadEXODual
Approx weight in KG
19.3 (with tubes)
Approx weight in LBS
42.55 (with tubes)
Max. System Weight
128 kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
